Water Guns
Komet Guns
-While conceiving new products, we must make sure
that they meet the values in which we strongly
believe: quality, reliability and a solid advantage to
the customer. The quality of a product is a reflection
of what the people who create, manufacture and
market it, stand for. This approach to our work is
very important to us.
-Reliability is achieved by using the most suitable
and functional materials for the intended
purpose as well as implementing the strictest
quality controls in every step throughout the
manufacturing process of our products. The
advantage to the customer is found in our efforts
to offer products of highest quality and reliability
combined with innovative features that we
implement in all of them.
-The Komet Twin big volume water gun sprinklers, available at our Auburn supply store, represents our capacity to integrate innovative technology, performance and reliability
12 nozzles
10.0 – 24.0 mm
0.39″ – 0.94″
5.4 – 56.4 m³/h
22 – 268 gpm
21.8 – 53.4 m
135 – 366 ft
17 nozzles
12.0 – 28.0 mm
0.47″ – 1.10″
7.8 – 79.2 m³/h
35 – 363 gpm
24.2 – 60.6 m
161 – 404 ft
19 nozzles
16.0 – 34.0 mm
0.63″ – 1.34″
13.8 – 116.8 m³/h
62 – 535 gpm
29.0 – 68.7 m
192 – 459 ft
21 nozzles
18.8 – 38.0 mm
0.71″ – 1.50″
21.7 – 168.0 m³/h
92 – 738 gpm
37.8 – 79.8 m
227 – 523 ft
24 nozzles
22.0 – 45.0 mm
0.87″ – 1.77″
32.4 – 235.0 m³/h
137 – 1032 gpm
41.5 – 90.0 m
247 – 590 ft
Nelson Big Guns
The Nelson 75 Series Big Gun comes as a Full (21° or 24° trajectory) or Part Circle (18° [HD only], 21°, 24°, or 43° trajectory) sprinkler with the Taper Ring Nozzle.
HD Lower Bearing, 12° Wedge Kit, Counterbalance Kit, Stream Straightener Vane. Can be fitted to a QC Valve or 2” 800 Series Control Valve.
1 1/2” or 2” FNPT or FBSP ANSI/DIN Nelson or Euro Flange
The Nelson 100 Series Big Gun comes as a Full or Part Circle sprinkler with an 18°, 21°, 24°, or 43° trajectory (or 15°- 45° adjustable trajectory). Taper, Taper Ring, or Taper Bore Nozzles are available (TR not available for SRNV).
Low-Pressure Drive Vane Kit, Counterbalance Kit, Secondary Nozzle Kit, 12° Wedge Kit and the Stream Straightener Vane. Can be fitted to a QC Valve or 2” 800 Series Control Valve
2” FNPT or FBSP, 2 1/2” FNPT ANSI/DIN, Nelson or Euro Flange for the F100 and SR100 - and the 2” FNPT or FBSP for SRNV100.
The Nelson 150 Series Big Gun comes as a Full Circle (21° or 24° trajectory), or Part Circle (21°, 24°, 27°, 43°, or 15°-45° adjustable trajectory) sprinkler. Taper, Taper Ring, or Taper Bore Nozzles are available.
Counterbalance Kit, Secondary Nozzle Kit, and Stream Straightener Vane. There is substantial thrust on a riser, so use a 3” valve minimum
Nelson, Euro or ANSI/DIN Flange (Also, Nelson Flange to Female Adapters).
The Nelson 200 Series Big Gun comes as a Full or Part Circle sprinkler with a 21°, 24°, or 27° trajectory. Taper Bore or Ring Nozzles are available.
Secondary Nozzle Kit (standard) and 12° Wedge Kit (SR200 only). There is substantial thrust on a riser, so use 4” valve minimum.
Nelson, Euro, or ANSI/DIN Flange (Also, Nelson Flange–to-Female Adapters).
